| Image Sensor: | 1/2.8”Sony415 8MP CMOS |
| Signal System: | PAL/NTSC |
| Min. Illumination: | Color: 0.05lux @(F1.2, AGC ON), 0 lux with IR |
| Shutter Time: | 1/25 s to 1/100,000 s |
| Lens: | 1.7mm Fisheye Lens |
| Day&Night: | IR cut filter with auto switch |
| Image Enhancement: | BLC/3D DNR/D-WDR |
| Motion Detection | Support |
| Privacy Protection | Support(4 Self-customized Areas) |
| Water-Proof: | IP66 |
| Illumination for Infrared Switching: | 0.5~3Lux |
| Infrared Wavelength: | 850nm |
| Mimimum Illumination: | 0 Lux(IR ON) |
| IR Range: | 3pcs Array IR Leds//15m IR |
| Compression Standard | |
| Video Compression: | H.265/H.264/MJPEG |
| Video Bit Rate: | 32Kbps~12288Kbps(CBR/VBR Selectable) |
| Audio Compression: | G711U/G711A |
| Dual Streams: | Yes |
| Triple Streams: | Yes |
| Image | |
| Max. Image Resolution: | 3840*2160@20fps(8MP) |
| Frame Rate: | 50/60Hz: Max.: 3840*2160@20fps |
| Sub Stream: | 50Hz/60Hz: Max. (800*488/704*576/640*360/352*288)@20fps |
| Third Stream(Mobile Stream): | 50/60Hz: (1080P/720P/CIF)@5fps |
| Image Settings: | 3D NR, D-WDR, Image Flip, Saturation, Brightness, Contrast, Sharpness adjustable via client software, web browser or Smartphone App |
| Day/Night Switch: | Auto(Passive Mode)/Day/Night/Auto(Active Mode)/Time |
| Network | |
| Network Protocols: | HTTP, TCP/IP, IPv4, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE,RTMP, DDNS, IP Search(Support Danale IP camera, DVR, NVS etc.) |
| General Function: | Anti-Flicker, heartbeat, password protection, privacy mask, Watermark |
| System Compatibility: | ONVIF(17.06 ) profile S/Danale(P2P) |
| On-line Viewing | Max. Support 6 Users Simultaneously |
| Interface | |
| Communication Interface: | 1 RJ45 10M / 100M Ethernet Interface |
| RCA Audio Interface: | RCA Audio input/output Interface (Optional) |
| DC Power Plug: | DC Power Female Interface |
| General | |
| Operating Conditions: | -10 °C ~ 60 °C |
| Humidity 95% or less (non-condensing) | |
| Power Supply: | 12 V DC ± 10%/PoE(Optional) |
| Power Consumption: | 12 VDC ± 10%, Max Power Comsumption Less than 8W (When the infrared lamps turn on) |
| Dimensions(D×H) | 130mm×54mm |
| Weight: | 0.66KG |
Network IP Cameras
VT-360N
Fisheye panoramic surveillance camera refers to a surveillance camera that uses a special wide-angle lens(commonly known as a fisheye lens) to achieve the largest range of viewing angles. The focal length of this surveillance camera is generally 1.7mm or shorter and the viewing angle can be close to 180°(horizontal direction) coverage, one unit can achieve large-area monitoring coverage without blind spots. The panoramic camera is mainly composed of multiple wide-angle lenses with different orientations at the same time to collect the surrounding images. After the image processing unit is corrected and spliced, a complete 360-degree image is formed the panoramic picture is transmitted to the recording host in real time and finally displayed.
